الوصف
| lnput SAT+TERR | 9+1 |
| Max. Output Level | Satelitte (IMA3) 102 dBmikroV |
| RF Connectors | F Connectors 75 ohm |
| DiSEqC | 2.0 -2.1 soltwore |
| DVB – T & DVB – C – HDTV | yes |
| Subscriber Output Lock Facillity | yes |
| Frequency Range TERR | 47- 870 MHz |
| Frequency Range SAT | 950 – 2150 MHz |
| SMPS Power Supply | 220 V / 18 Vdc/ 2000 m |
| Max. Current Consumption | 650 mA |
| lsolation SAT Subscriber-Subscriber | > 34 dB |
| lsolation SAT-SAT | > 34 dB |
| lsolation SAT-TERR | > 36 dB |
| lsolation H/V | > 34 dB |
| Number of Subscriber Outputs | 8 |
| Number of Cascade Outputs | 9+1 |
| Side Gain TERR | – 1 dB±1 |
| Side Gain SAT | + 2 dB±1 |
| Cascade Output Terr | – 3dB±1 |
| Cascade Output Sat | – 1dB±2 |
| Dimensions | 210x120x45mm |
| Weight | 481Gr. |
